Specim GX17 is a fast-operation push-broom hyperspectral camera operating in the NIR spectral range (980-1730 nm). The GX17 identifies objects that are invisible to the human eye on conveyor belts and free fall systems moving at high speed. It is a powerful and accurate tool for inline sorting, inspection, and quality control and offers the best cost–performance ratio in high volumes.
2. Input your working distance below in millimeters to calculate the Field of View
Parameter
Value
Object length (mm)
Object width (mm)
Depth of field (mm)
Sampling/pixel size (mm)
Minimum working distance (mm)
3. Input the requested Field of View value in millimeters to calculate the Working Distance
*)This is the same as Object length (mm) above.
Parameter
Value
Working distance (mm)
Object width (mm)
Depth of field (mm)
Sampling/pixel size (mm)
Minimum object length (mm)
Glossary of the used terms
Working distance The distance from the object to the first lens surface.
Object length The size of the object in the direction perpendicular to the scan direction of a line imaging camera, also known as the across-track field of view.
Object width The size of the object in the scan direction of a line imaging camera, also known as the along-track field of view.
Depth of field The approximate depth of field calculated using modeled root mean square (RMS) spot diameter as the circle of confusion.
Sampling/pixel size The across-track pixel size at the object with the smallest binning setting (usually 1 bin) of the camera, also known as the across-track geometrical pixel field of view.
Minimum working distance The minimum working distance defined by the lens design. With macro lenses, this is the only distance where the lens can be used.
Information in this document is subject to change without notice. Specim, Spectral Imaging Ltd. reserves the right to change or improve its products and specifications and to make changes in content without obligation to notify any person or organisation of such changes or improvements. Please note that the calculated values are for reference use only.
MAIN FEATURES AND BENEFITS
HIGH-PERFORMING
High spatial resolution, image speed, light-throughput, and signal quality
ACCURATE
50% more pixels compared to conventional QVGA (320px) sensor-based HSI cameras
COST-EFFECTIVE
The best cost–performance ratio HSI NIR camera in high-volumes
SPECIM GX17 CAMERA IS IDEAL FOR:
Hyperspectral imaging in recycling and waste management
Hyperspectral imaging in food quality and safety
Hyperspectral imaging for mining and mineral exploration
Hyperspectral imaging in pharmaceutics and medical
Surface and coating inspection
Hyperspectral imaging in agriculture and vegetation
